Introduction
Chemical processing plants present complex challenges for fire detection. High ceilings, multi-level structures, dense pipework, and contamination from dust, steam, and chemical vapours create conditions where conventional systems struggle to provide reliable coverage. This study reviews a project where a specialist fire detection system was successfully implemented to overcome these issues.
Facility Overview
The facility in question was a large chemical processing building with multiple mezzanine floors, extensive tank and pipe networks, and an internal height of approximately 20–21 metres. Existing detection relied on aspirating technology, which was proving unsuitable due to the operational environment.
The Challenge
The existing aspirating smoke detection system operated by drawing air samples through a network of perforated pipework. In practice, the system faced several issues:
· Dust, dirt, and chemical vapours were constantly drawn into the system, clogging filters and pipework.
· Optical smoke detectors within the aspirating unit could not differentiate between smoke, steam, and dust, leading to frequent false alarms.
· The system had been disabled due to ongoing reliability problems.
Additionally, the facility’s scale and ceiling height meant that smoke from a developing fire could cool and stratify before reaching ceiling-mounted detectors, delaying or preventing detection.
The Solution
Working with the fire engineering contractor, a specialist video flame detection system was selected to address the unique risks. The design process involved:
· Developing a detailed 3D model of the facility, incorporating mezzanine levels, tanks, and pipework.
· Positioning detectors to provide optimal coverage of complex areas while balancing budget considerations.
· Using a combination of wide-angle and long-range video flame detectors, selected for their ability to operate in dusty, steamy, and chemically active environments.
· Implementing measures to manage potential false triggers from reflective surfaces and sunlight, including coincidence detection and light sensors.
The final design utilised twelve detectors in total, installed and commissioned to provide complete coverage of the facility.
Outcomes
The project delivered a system that:
· Ignored dust, steam, and vapour, only responding to the flicker of actual flames.
· Operated effectively in full daylight, darkness, and challenging industrial conditions.
· Reduced installation and commissioning time significantly compared to an aspirating system (less than one week, versus several weeks with scaffolding).
Importantly, the system was compliant with BS 5839-1 requirements for fire alarm systems, including the use of fire-rated cabling and 24-hour battery backup capacity.
Lessons Learned
This case highlights several key points for fire engineering in complex environments:
· Traditional aspirating or ceiling-mounted smoke detection can be unsuitable where dust, vapour, or stratification are present.
· Video flame detection offers a robust alternative for high-risk industrial environments, provided that careful modelling and commissioning are undertaken.
· False alarm management is critical to maintaining trust in fire alarm systems; coincidence detection, masking, and sensitivity adjustments play an important role.
Conclusion
The adoption of video flame detection in this chemical processing facility demonstrates the value of specialist systems in environments where conventional solutions are ineffective. By combining careful modelling, engineering collaboration, and tailored commissioning, a reliable and compliant solution was achieved, delivering confidence to both the fire engineering contractor and the end user.
